Perfect for ultra-compact high output speakers systems, Celestion's FTX0820 8" coaxial full-range features fully integrated low and high frequency drivers which are powered by a common motor assembly. Bringing the acoustic centers of the two drivers closer together improves both time alignment and signal coherence for more natural and predictable response. Other features include an aluminum demodulation ring, edgewound voice coils (woofer and compression driver), and a cast aluminum frame with integrated voice coil vents.
By concentrically aligning low and high frequency drivers, coaxial loudspeakers act as a single source, often providing improvements in signal alignment when compared to a traditional two-way system. Powered by a common magnet motor assembly (same magnet for both elements) Celestion's FTX coaxial range features fully combined LF and HF components in a single chassis. This brings the voice coils and hence the acoustic centers of the two drivers closer together, delivering further improvements in signal coherence for a more natural sounding audio reproduction.
Specifications (Woofer): • Power Handling: 200 watts RMS/ 400 watts continuous program • VC dia: 2" • Le: 0.84 mH • Impedance: 8 ohms • Re: 5.9 ohms • Frequency response: 70 – 4,000 Hz • Fs: 63.9 Hz • SPL: 94 dB 1W/1m • Vas: 0.75 cu. ft. • Qms: 4.7 • Qes: 0.24 • Qts: 0.23 • Xmax: 2 mm
Specifications (Compression driver): • Power handling: 40 watts RMS/ 60 watts continuous program (with recommended crossover of 2,200 Hz/12 dB slope) • VCdia: 1.4" • Impedance: 8 ohms • Frequency response: 1,500 – 20,000 Hz • SPL: 103 dB 1W/1m
Dimensions: • Outside diameter: 8.5" • Cutout diameter: 7.36" • Depth: 4.49"
