This compact micro amplifier features a heavy-duty heatsink and a small footprint, making it easy to install in vehicles, motorcycles, and 4-wheelers. With dimensions of 9″ W x 5.90″ L x 2.60″ H, it’s designed for tight spaces without compromising performance. Delivering 4 x 500 watts at 2 Ohm TRUE RMS, this amplifier utilizes advanced Digital Class D Brazilian Technology, providing precise power distribution for multiple speakers. In bridged mode, it doubles the power output to 2 x 1000 watts RMS at 4 Ohms per bridged channel, offering robust performance for demanding audio setups. Built with the latest surface-mount technology, it ensures superior vibration resistance and exceptional sound quality, making it the ultimate choice for audio enthusiasts and competitors looking to create their dream systems.
This amplifier’s high-power output and multichannel technology eliminate the need for multiple units, offering versatile 4, 3, or 2-channel configurations to suit your system's needs.
The MDX Series is designed for motorsport applications, making it a perfect fit for custom motorcycles, ATVs, and Slingshots.
500 Watts at 2 Ohm per Channel 1000 Watts at 4 Ohm per Bridged Channel
High output performance in a compact, space-saving design!
Equipped with a mini heavy-duty heatsink and built-in cooling fan to stay cool during intense playlists.
Weighing just 3.85 pounds, it offers an exceptional performance-to-weight ratio for custom systems.
Before InstallingYou must follow the instructions for the product’s installation to guarantee optimal performance. If you have any questions, get in touch with us. Before using the amplifier, always follow these guidelines:
Make sure the amplifier is switched off before adding or removing any connections. This prevents possible damage to equipment. Keep all cables as far away as possible from the ignition cables, electronic injection modules and starter switch since they may cause noise interference; Minimum recommended installation distance between amplifier is 1.25”. Always use OFC 4 AWG Copper wire for power and ground and minimum of 12 AWG speaker wire and good quality connectors. Copper-clad aluminum wire (CCAW) must not be used. This guarantees reliability and performance. To avoid damaging the cables, make sure that they do not touch sharp metal edges. Important: For this amp use a 100A fuse 12 inches away from the battery as a safety precaution.
The power rating data is based on equipment from the PRV Audio Group laboratory. Rated power tested with 60Hz to 1KHz sinusoidal signal and THD
Specifications
Impedance: 2 Ohm per ChannelChannels: 4 Channel Rated RMS Power at 14.0 V at 2 Ohm: 4x 500 Watts RMS Rated RMS Power at 14.0 V at 4 Ohm: 4x 330 Watts RMSBridged Rated RMS Power at 14.0 V at 4 Ohm: 2x 1000 Watts RMS Average Efficiency: 88% Operating Voltage: 8 to 16 Volts Musical Current Draw: 91 A Minimal Power Wire Input: (OFC) 4 Gauge wires Built-in Crossover: Fixed HPF & LPF at 80 HzMinimal Speaker Wire Output: 12 GaugeFrequency Response(-3dB): 10 – 22,000 Hz Min. Input Sensitivity for Max. Output: 0.2 to 2v Signal Input: RCA Cables Signal to Noise: >90 dB Protection System: High Temperature / Short circuit on Output Heat Sink Type: Mini Heavy Duty Cast Aluminum Dimensions ( Width x Depth x Height ): 9.00" x 5.90" x 2.60"Weight 3.85 lbs.
