The GF 200's design allows for integration into various cabinet sizes, with manufacturer recommended volumes ranging from 30 liters to 70 liters in bass reflex configurations, achieving tuning frequencies between 27 Hz and 40 Hz. This versatility makes the GF 200 an excellent choice for audiophiles and speaker builders aiming for superior low-frequency performance in their custom speaker designs.
Technical Data
Rated power: 120 WMaximum power: 180 WNominal impedance Z: (1) 4 Ohm (2) 8 Ohm (3) 2 OhmFrequency response: fu–8000 Hz (fu: Lower cut-off frequency depending on cabinet)Mean sound pressure level: (1) 85 dB (1 W/1 m) (2) 88 dB (1 W/1 m) (3) 88 dB (1 W/1 m)Opening angle (-6 dB): 46°/4000 HzExcursion limit: ±10 mmResonance frequency fs: (1) 34 Hz (2) 30 Hz (3) 35 HzMagnetic induction: 1.3 TMagnetic flux: 930 µWbHeight of front pole-plate: 6 mmVoice coil diameter: 38 mmHeight of winding: 18 mmCutout diameter: 190 mmNet weight: 2.5 kgD.C. resistance Rdc: (1) 2.9 Ohm (2) 5.8 Ohm (3) 1.4 OhmMechanical Q factor Qms: (1) 4.51 (2) 4.12 (3) 4.33Electrical Q factor Qes (1) 0.93 (2) 0.37 (3) 0.44Total Q factor Qts: (1) 0.77 (2) 0.34 (3) 0.39Equivalent volume Vas: (1) 62 l (2) 68 l (3) 57 lEffective piston area Sd: 214 cm²Dynamically moved mass Mms: 25 gForce factor Bxl: (1) 4.6 Tm (2) 9.2 Tm (3) 4.6 TmInductance of the voice coil L: (1) 0.4 mH (2) 1.1 mH (3) 0.3 mHConnections: 4.8 x 0.8 mm (+)/2.8 x 0.8 mm (-)
